[HDBH-102] 4K BNC to FHD HDMI Converter Convert HD TVI/ CVI/ AHD Analog video signal to HDMI
**PROMOTION NOW**
Description:
Overview Analog HD BNC-HDMI converter converts HD TVI/AHD/CVI & Composite Video signal from BNC to HDMI connector so that an Analog HD TVI/AHD/CVI/ Composite camera can connect to a HDMI monitor directly. This enables High Definition video feed from Analog HD TVI/AHD/CVI/Composite camera to be viewed without going through a DVR first.
Feature Points:
-
Converts Analog HD TVI/AHD/CVI & Composite Video signal from BNC to HDMI effectively
-
TVI/AHD/CVI/CVBS Input (BNC) x 1 & Loop Out (BNC) x 1
- Lossless real time non-compression conversion
-
Supports Analog HD TVI/AHD/CVI/Composite V4.0 resolution: HD 720P @25/30/50/60 FPS, HD 1080P @25/30 FPS. 3MP @18/25/30 FPS,4MP @15/25/30 FPS, 5MP @12.5/15 FPS, 4K (8MP) @12.5/15 FPS
- HDMI output x1, V1.4b
- Coaxial cable impedance: 75 Ohm
- Plug and Play, no driver needed
-
LED indicators for power and HD TVI/AHD/CVI/CVBS signal source sync.
- Fully enclosed dust-proof housing w/mounting ear
- Up to 100,000 life time hours of MTBF
Specification:
|
Model |
HDMI Converter: HDBH-102 |
|
Physical Interface |
Input: BNC x 1 , Output: BNC x 1 , HDMI x 1 (D-type base) |
|
TVI/AHD/CVI/CVBS Input/Loop Out Format |
Analog HD TVI/AHD/CVI/CVBS-V4.0, 4K (8MP) 12.5/15 FPS, 5MP 12.5/20 FPS, 4MP 15/25/30 FPS, 3MP 18/25/30 FPS, 1080P 25/30 FPS, 720P 25/30 FPS, 500 ~700 mVp-p |
|
Input Cable |
Support 75-Ohm coaxial cable input with 100 M distance |
|
Input Impedance |
75 Ohm |
|
HDMI Output Format |
HDMI 1.4b, standard interface |
|
Output Resolution |
1080P 50/60 & 720P 50/60 |
|
Output Cable |
HDMI 1.4b, D-type base, 10 M distance |
|
LEDs |
Power LED x 1, Video Source Sync LED x 1 |
|
Power Supply |
DC 5V, 1A |
|
Power Consumption |
≤ 8 W |
|
Working Humidity |
30 % to 90 % |
|
Working Temperature |
14º F to + 122º F (-10º C to + 50º C) |
|
Dimensions (W×D×H) |
4.3 × 3.7 × 0.98 inch ( 109 × 94 × 25 mm) |
|
Weight |
0.4lb / 0.18Kg |
- Converts Analog HD TVI/AHD/CVI/CVBS signal from BNC to HDMI effectively, Analog HD Input (BNC) x 1 & Loop Out (BNC) x 1
- Supports Analog HD TVI/AHD/CVI/CVBS V2.0 resolution: HD 720P @25/30/50 & 60Hz, HD 1080P @25 & 30Hz, HDMI output x1, V1.4b
- Lossless real time non-compression conversion, Coaxial cable impedance: 75 Ohm
- Plug and Play, no driver needed, LED indicators for power and Analog HD TVI/AHD/CVI/CVBS signal source sync. Up to 100,000 life time hours of MTBF
What's in the Box?
HD AHD/TVI/CVI/ANALOG Converter x1, Power supply x 1
